Primus D13 - Will Not Heat - Electric

82 70284701
Section 7 Electronic Control Troubleshooting
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
WILL NOT HEAT – ELECTRIC
(Sheet 2 of 2)
T035D
Replace the stove
limit.
Is there voltage to the
output side of the stove
limit?
Correct wiring to
the coils of HC1
and HC2.
Is there voltage across
coils HC1 & HC2?
Correct wiring
between elements
and supply. Replace
HC1 and or HC2
if necessary
Is there voltage across
the heating elements?
Replace elements.
Do the elements
produce heat?
Unit operational.
NO
YES
NO
YES
NO
YES
NO
YES
T035D
