Printronix Auto ID T820 - Ribbon; Indicators and Switches

236
Table 16. Media Specifications
T820
T830
Continuous/Batch Mode
0.25in – 50in
6.35mm to 1270mm
Tear-Off Strip Mode
1.96in – 50in
50mm to 1270mm
Peel-Off Mode
1.0in – 6.0in
25.4mm – 152.4mm
D
Cut Mode
1.0in – 50in
25.4mm – 1270mm
These figures are approximate and depend upon the active emulation and application.
Ribbon
Table 17. Ribbon Specifications
T820
T830
Ribbon Width Range
1.0 -4.4 in.
25.4 -112 mm
1.0 -4.4 in.
25.4 -112 mm
Max. Ribbon Length
300m
300m
Max Ribbon Roll
Diameter
2.68 in
68mm
2.68 in
68mm
Indicators and Switches
Table 18. Indicators and Switches
Indicator Lights:
ONLINE
Switches:
POWER
Keys:
PAUSE, F EED , LEFT SOFT KEY, RIGHT
SOFT KEY, UP / DOWN / LEFT / RIGHT
ARROW KEYS ,  (ENTER)
Message Display:
320 x 240 Color QVGA display
