Sensing Different Media Types
The printer’s media sensors can detect the different types of label length
indicators on a large variety of
media types. This is accomplished by selecting
the correct sensor option: Gap, Mark, or
Disable under
Sensors > Control > Gap/Mark Sensor menu or within the “Printer Setup” Wizard.
1. Press the PAUSE key to place the printer OFFLINE (Home Screen).
2. Find the Settings ICON and press ENTER.
3. Press the UP + DOWN ARROW keys together until “ENTER SWITCH UNLOCKED” displays.
4. Find the Sensors ICON and press ENTER.
5. Select the “Control” submenu and press ENTER.
6. Find the “Gap/Mark Sensor” option and press ENTER to edit this menu. Find the option that matches
the type of label length indicators on the installed media displays:
Disable. Select when using media with no label length indicators (no
gaps, notches, holes, or black
marks) or when you want the printer to
ignore all existing label length indicators on the installed media.
Mark. Select when using media that has horizontal black marks
located on the underside of the label
liner or tag stock or when using media with notches or holes as label length
indicators.
Gap. Select when using media with a liner space between die-cut
labels or has horizontal black marks
located on the topside of the label.
NOTE: When you select Disable, the length of each label is based on the
Media > Image > Label
Length menu or the value
sent via host software.
NOTE: If the printer detects a false PAPER OUT message when you change
to Gap or Mark sensing
or
vice-versa, find the Home Screen and run Calibrate
7. Press ENTER to enable the displayed option or use the RIGHT SOFT key labeled “Apply”. An asterisk
(*) appears next to the selection
.
8. Press the PAUSE key or the LEFT SOFT key labeled “Home” to return to the Home Screen.
9. Review Media with Gaps
10.
1. Media with a horizontal liner space between die-cut labels or horizontal black marks located on the
upper side of the label liner.
2. Select “Gap” in the Sensors > Control > Gap/Mark Sensor menu.
3. Perform an Auto Calibrate. See Running Auto Calibrate on page 38.
11. Calibrating the Media Sensors on page 37. Perform the Auto Calibrate procedure per Running Auto
Calibrate on page 38.
