Media > Auto Label Map > Auto Label Width
The width of a single label to be printed or the maximum width of the media
that will be used for the print file. The value is selectable from 0.1 inch through
the maximum print width of the printer.
Minimum
0.1 inch
Maximum
Media > Image > Label Width value.
Factory Default
Depends on the model width.
Media > Auto Label Map > Number Labels
The desired number of labels to be printed vertically adjacent on the form.
Minimum
2
Maximum
40
Factory Default
2
Auto Label Map Examples
All of the examples below assume that the logical form length is set to the label length.
Example 1: Simple Case
Problem: A file has been constructed with two horizontally adjacent 4.0” labels
for a printer with a physical
width of 8.0”. The user now wants to use this file
with a printer that has a 4.0” physical width.
Solution with Menu Settings:
• Set Media > Auto Label Map > Auto Label Width to “4.0” (the width of the label)
• Set Media > Auto Label Map > Number Labels to “2”
• Set Media > Auto Label Map > Select to “Enable”.
Printer Operation: The printer will print the first (leftmost) 4.0” label first on the first thermal label, followed
by the second 4.0” label. These labels will be stacked vertically as shown in the diagram.
