Settings Organization
This section will show how the configuration menus are organized under the icons in the Settings section.
Screen #1
Quick Setup
Media
Sensors
Application
Configs
Admin User
Media
Speed
Handling
Ribbon
Top of Form
Faults
Auto Label Map
Sensors
Control
Calibrate
Diagnostics
System
Control
Energy Star
Flash File View
Flash File Edit
SD File View
1
SD File Edit
1
Printer Mgmt
Date
Host I/O
Control
USB
Serial
Network
Control
Ethernet
3
WLAN
2
WLAN Params
2
WLAN EAP
2
Screen #2
Application
Control
PGL … MGL Setup
LP+ Setup
P-Series … Setup
Fonts
RFID
4
Control
Custom Tag
Diagnostics
Statistics
Tools
Print Tests
Diagnostics
Statistics
About
Configs
Control
Custom
NOTE:
1
The SD related submenus will only show when the SD card is installed.
2
WLAN is an option and these submenus are included only when WLAN is installed.
3
Ethernet menu is not available if WLAN option is installed unless an Ethernet cable is attached at
power-up.
4
RFID is only available when the RFID option is installed. Refer to the RFID Labeling Reference
Manual for information on these menus.
