Printronix Auto ID T820 - Page 66

66
Media > Image > Print Direction
This option is the compass for print orientation. Not all IGP Emulation
languages have the same definition of Portrait, Landscape, etc. The
illustration below shows how Portrait is defined for both Head First and Foot
First.
Head First
With Orientation set to Portrait, the top of the label will
come out of the printer first.
Foot First
With Orientation set to Portrait, the bottom of the label
will come out of the printer first.
Factory Default
Head First for PGL, but Foot First for ZGL. It will
automatically be set for plug’n play compatibility.
IMPORTANT
Print Direction will not change the orientation of
any print test patterns in the Tools > Print Tests
menu.
