Printronix T5000 - Environmental; Physical; Acoustic Specifications

274
Appendix A
Environmental
Physical
Acoustic Specifications
Table 25. Environmental Information
Operating Temperature: 41° F to 104° F (5° C to 40° C)
Storage Temperature: -40° F to 150° F (-40° C to 60° C)
Operating Humidity:
Storage Humidity:
20% to 85%, non-condensing
5% to 85% non-condensing
Ventilation: Free air movement
Dust: Non-conducting, non-corrosive
Table 26. Physical Dimensions
T5X04 T5X06 T5X08
Outside Dimensions (in.) 13H x 11.7W x
20.5D
13H x 13.4W x
20.5D
13H x 15.4W x
20.5D
Max. Weight (lbs/kg) 39 lbs.
17.55 kg
45 lbs.
20.25 kg
48.5 lbs.
21.83 kg
Add 1.75" D with media guide installed
Add 7.5" D and 6" H for validator option
Add 1.4" D for media cutter option
Table 27. T5000 Acoustic Noise Levels per ISO 9296
T5X04 T5X06 T5X08
Printing @ 6 IPS 68 dBA 62 dBA 62 dBA
Standby: 37 dBA 37 dBA 37 dBA
