MACHINE DESCRIPTION
UM-PSPC-06-E/10-2012 USER MANAUL PSPC Page 31 of 99
OPTIONAL STAMPING UNIT
Use:
The stamping unit is designed for coding eggs.
Construction:
The stamping unit consists of:
1 Shaft with stamps
2 Hinging frame
3 Drive mechanism
The stamping unit is placed above the cup
conveyor close to the transfer position of eggs
from roller track to cup conveyor.
Process:
After a step forward of the roller track and the
cup conveyor, the shaft with stamps moves
down to code the row of eggs in the cup
conveyor.
Safety:
The stamping unit is covered but since this is
not a safety cover with an open cover it is
possible to sustain injury.
The cover above the stamping unit doesn’t
have a safety switch. With an open cover, the
system remains running.
CAUTION!
The cover above the flap shaft is NOT a safety
cover. Opening this cover does NOT stop the
system.
ATTENTION!
Do not enter objects or body parts into the
stamping unit when it is running production.
TIP!
Do not store the stamps and ink into a room
with a temperature below 12ºC. Below this
temperature, the ink becomes syrupy resulting
in bad coding on the eggs.
