M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Model Number (Continued):
LUF-130-3LL6-SK
    
 Heater Inlet, Outlet Plumbing Connections.
The heater inlet and outlet plumbing connections are usually the same. However, it is possible to have
different plumbing connections for the inlet and outlet. The characters to describe the plumbing
connections have the same designation for both the inlet and outlet connections. Please refer to the table
below to see the specific plumbing connections provided with the heater:
Heater Model
Number
Plumbing Connection Type
Plumbing Connection Size: mm (in)
A
Flared Tube Fitting
13mm (1/2-inch)
B
Flared Tube Fitting
19mm (3/4-inch)
C
Flared Tube Fitting
25mm (1-inch)
D
Union manifold Connector
32mm (1 ¼-inch)
E
Flange
19mm (3/4-inch)
F
NPT Pipe Threads, Female
13mm (1/2-inch)
G
NPT Pipe Threads, Female
19mm (3/4-inch)
H
NPT Pipe Threads, Female
25mm (1-inch)
I
NPT Pipe Threads, Male
13mm (1/2-inch)
J
NPT Pipe Threads, Male
19mm (3/4-inch)
K
NPT Pipe Threads, Male
25mm (1-inch)
L
Butt Fusion Union
25mm (1-inch)
M
BCF Union
32mm (1 ¼-inch)
N
Socket Fusion Union
32mm (1 ¼-inch)
P
Pillar Tube Fitting
13mm (1/2-inch)
Q
Pillar Tube Fitting
19mm (3/4-inch)
R
Pillar Tube Fitting
25mm (1-inch)
U
Socket Fusion Union (Standard)
25mm (1-inch)
 Flow Meter Device. The ultrasonic flow meter device is part of the DAC temperature control system.
The flow meter is selected based upon total wattage of the heater and operating flow rate range. This
device does not require routine maintenance or re-calibration.
Heater Model
Number
Device
Brand
Water Flow
Range
Process Technology
Part Number
0-4
5
Thornton
2-20 LPM
8136
6
Thornton
10-70 LPM
8137
7
Honda
0.5-20 LPM
9238
8
Honda
1-50 LPM
09-6820
9
Thronton
15-150 LPM
9964
