4-20 High Level
Setpoint
PID – Proportional
Band
Level ESDs Location
4-20 Low Level
Setpoint
PID – Integral Thermocouple Errors
4-20 Pressure Setpoint PID – Derivative Terminal Errors
4-20 Low Pressure
Setpoint
System Errors
Flame View Event Log
Aux Temp Clear History
4-20 Level Reading
4-20 Pressure Reading
Alarms
Menu 4
System Startup
Menu 5
Control Setup
Menu 6
Expansion Cards
Auto Restart
High Temp ESD
Setpoint
4-20 Expansion Card
Enable
Purge Time Process Control In-put 4-20 Level Units
Pilot to Main Delay Low Fire Enable 4-20 Level Range
Restart Attempts Low to High Fire Delay 4-20 Level Offset
Level Event Restart Pilot off Enable 4-20 Level Low Setpoint
Pressure/Level Delay AUX Temp Mode 4-20 Level High Setpoint
Pressure Restart 4-20 Pressure Units
Alarm Mode 4-20 Output Mode 420 Pressure Range
Password Enable 4-20 Low Fire Setting
4-20 Pressure Low
Setpoint
Display Sleep
4-20 Pressure High
Setpoint
Pilot Valve Power
Setting
MODBUS
Enable/Address
Main Valve Power
Setting
4-20 Card FW Version
System Voltage Setting
MODBUS
Card FW Version
Temperature Display
Units
Commission Date
Entry
Commission Location
Entry
Rest to Factory
Defaults
SETPOINTS (MENU 1)
This menu is used to adjust the Process Control Setpoints.
MENU MAP ON SCREEN BRIEF DESCRIPTION RANGE DEFAULT SETTING
Pilot Off Setpoint Pilot Off
Setpnt
Adjusts the temperature at which the
Pilot Valve will turn off when Pilot Off is
enabled.
1 to 1349˚C
34 to 2460˚F
85˚C
185˚F
Low Fire Setpoint Low Fire
Setpnt
Adjusts the temperature at which the
Low Fire Valve will turn off when Low
Fire is enabled.
2 to 1349˚C
36 to 2460˚F
Hidden, 85˚C
185˚F
Process Setpoint Proc
Setpnt
Adjusts the temperature at which the
High Fire/Main Valve will turn off
1 to 1349˚C
34 to 2460˚F
80˚C
176˚F
Low Temp Alarm Setpoint Low Temp Alarm
Setpnt
Adjusts the temperature where the
Status Contact will close, if enabled.
Disabled,
1 to 1349˚C
34 to 2460˚F
Disabled
Deadband Deadband Adjusts the Deadband. Used with the
Process Setpoint and sometimes Low
Fire and Aux Setpoints.
1 to 150˚C
1 to 240˚F
2˚C
3˚F
Aux Setpoint AUX Setpnt Adjusts the Auxiliary Setpoint 0 to 1350˚C
32 to 2462˚F
Hidden, 20˚C
68˚F
PID – Proportional Band PID
PB:
Expressed in percent, this is inversely
proportional to the PID controller’s
proportional gain.
0.0 to 999.9% 10.0%
PID – Integral PID
I:
Expressed in Minutes per Reset, this is
the amount of time required for the PID
integral term to yield the same output as
the proportional term.
0.0 to 999.9
min/rst
4.0 min/rst
PID – Derivative PID
D:
Expressed in Minutes, this causes
the PID to compensate based on the
changing error. Disabled by default
0.0 to 999.9
min
0.0 min
HISTORY (MENU 2)
This menu contains informational event counters and the event log.
MENU MAP ON SCREEN BRIEF DESCRIPTION RANGE DEFAULT SETTING
Relights Re-Lights Number of Pilot Relight attempts. 0 to 1000 N/A
Flame Fails Flame Fails Number of Shutdowns due to failure to
light the pilot.
0 to 1000 N/A
Resets Resets Number of power failures or manual
resets.
0 to 1000 N/A
ESDs ESDs Number of system shutdowns caused
by faults.
0 to 1000 N/A
