SPECTRUM 3/3: FULL SPECTRUM
∗
Figure 29.
Selected installation, date and time.
Number of view/total views.
Joystick active mode, selected band, battery level.
Spectrum in the band with the selected span.
Softkeys menus.
► Joystick up/down: It changes the reference level.
► Joystick left/right (depending on the joystick active mode):
SP: SPAN change.
FR or CH: Frequency change or channel change.
MK: Marker change.
∗
Only available for digital channels.
April 2013
4-37
