MR-20 OPERATOR’S GUIDE
23
Cable Connections for External Pelvic Floor:
Connecting the Pathway
®
Adapter (Part #3660) to the 24” Electrode Lead
Wire Set (Part #5328), and Easytrode
™
Pregelled Electrodes (Part #6801)
CHAPTER 1: PHYSICAL/MECHANICAL OVERVIEW
24” Electrode Lead Wire Set
Use with Easytrode
™
Pregelled Electrodes
(Part #5328)
Easytrode
™
Pregelled Electrodes, Bag of
150 (Square Individual Snap Style)
Use with 24” Electrode Lead Wire Set or 6’
Electrode
™
Lead Wire Set (Part #6801)
Note: The 24” Electrode Lead Wire Set (Part #5328) consists of two red (active) lead
wires and one green (ground) lead wire.
To obtain best EMG results, the following steps should be taken:
Connecting 24” Electrode Lead Wire Set to Pathway
®
Adapter: To connect the 24”
Electrode Lead Wire Set (Part #5328) into the Pathway
®
Adapter (Part #3660),
EMG A: To monitor primary muscle
EMG B: Accessory muscle placement:
Commonly monitored accessory muscles
include abdominals, leg adductors, & gluteals
