5
Vess A2200 Quick Installation Guide
Note
Please refer to the Quick Installation Guide included with
the mounting rails for more detailed rack installation
instructions.
Figure 5: Vess A2200/A2200s with rail brackets and handles attached
FollowthemountingrailinstructionstoattachtheRailbracketsoneachsideoftheen-
closure,andthehandlesonthefront.
ToinstalltheVessA2200/A2200sintoarackwiththesuppliedmountingrails:
1. Checkthetofthemountingrailsinyourracksystem.
2. Adjustthelengthofthemountingrailsasneeded.
Figure 6: Installing the rails onto the rack
left side rail viewed from front right side rail viewed from front
