Vess A2200 Quick Installation Guide
Figure 13: SATA disk drive mounted in a drive carrier
NumbeR of DRiveS RequiReD
ThetablebelowshowsthenumberofdrivesrequiredforeachRAIDlevel
Level Number of Drives Level Number of Drives
RAID0 1ormore RAID6 4to32
RAID1 2only RAID10 4ormore*
RAID1E 2ormore RAID30 6ormore
RAID3 3to32 RAID50 6ormore
RAID5 3to32
*Mustbeanevennumberofdrives.
Counter-sink
screws
(two screws on
each side)
