PROMISE Technology
steP 1: shUt down systeM, disconnect Power
Beforeopeningthesystemhousing,shutdownthedeviceanddisconnectanypower
cords.
steP 2: reMoVe hoUsing coVer
Figure 30: Remove housing cover
1. UseasmallPhillipsheadscrewdrivertoremoveallvescrewsthatsecure
thecovertotherestofthedevicehousing.Therearetwosmallathead
machinescrews,oneoneachside,andthreedomeheadmachinescrews
thatsecurethecovertothebackplate.
2. Slidethecovertowardtherearofthedeviceuntilitcanbeliftedoff.
