TAsk 5: connecTing The poweR
Insertonepowercableintothepowerreceptacleforeachpowersupplyandconnect
theeachPSUtoasuitablepowersource.TheVessA2200sisequippedwithasingle
powersupply(seebelow).TheVessA2200isequippedwiththreepowersuppliesin
anN+1arrangement.See“Figure17:VessA2200rearpanelN+1powerconnections”
onpage15.
Figure 16: Vess A2200s rear panel power connection
TheVessA2200featuresthreeN+1powersupplies.Inthisarrangement,onePSUis
redundant,soaminimumoftwoPSUsareneededtopoweruptheVessA2200.
PSU cooling fan
Power cord
receptacle
Power switch
pictured in
“ON” position
