Vess A2200 Quick Installation Guide
Caution
The Vess A2200/A2200s supports disk drive hot-
swapping. To avoid hand contact with an electrical
hazard, do not remove more than one drive carrier at a
time.
Drive numbers
(odd)
Drive numbers
(even)
DRive Slot NumbeRiNg
Youcaninstallanysuitablediskdriveintoanyslotintheenclosure.Thediagrambe-
lowshowshowdriveslotsarenumberedonboththeVessA2200sandVessA2200.
SlotnumberingisreectedinthewebmanagerGUIandCLI/CLUuserinterfaces.
Figure 11: Drive slot numbering for Vess A2200s/A2200
Installallofthedrivecarriersintotheenclosuretoensureproperairow,evenifyoudo
notpopulateallthecarrierswithdiskdrives.
