Vess A2200 Quick Installation Guide
Figure 3: Vess A2200s rear view
Figure 4: Vess A2200 rear view
TheVessA2200isidenticaltotheVessA2200sexceptthatitincludesanN+1power
supplyarrangement.
PSU fan Power switch
USB ports
USB 2.0 on left
USB 3.0 on right
Audio In/Out HDMI port
Network ports
and LED indicators
See “Task 4: Management Connections” on page 12
Power insert
See “Task 5: Connecting the Power” on page 14
RS-422 / RS-485 ports
Sensor input / Alarm output
Covers for PCIe card access
PSU fans
Power inserts
See “Task 5: Connecting the Power” on page 14
