MVI56E-GSC/GSCXT ♦ CompactLogix or MicroLogix Platform Reference
Enhanced Generic ASCII Serial Communication Module User Manual
ProSoft Technology, Inc. Page 87 of 140
April 24, 2017
Byte Offset
Description
228 to 229
Number of blocks transferred from module to processor
230 to 231
Number of blocks transferred from processor to module
232 to 233
Number of blocks parsed by module
234 to 235
Number of block errors in module
Port 1 Status
Byte Offset
Description
236 to 237
Port 1 receive state:
-1 = Listening for data
1 = Receiving Port Data
2 = Waiting for Backplane transfer
238 to 239
Port 1 receive character count
240 to 241
Port 1 receive block count
242 to 243
Port 1 transmit state:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
244 to 245
Port 1 transmit character count
246 to 247
Port 1 transmit block count
248 to 249
Port 1 error word
250
Reserved
Port 2
Byte Offset
Description
251 to 252
Number of characters (0 to 200) in Port 2 receive block (255 to 454). If the receive
data in the module is larger than 200 bytes, multiple blocks will be transferred. Any
block with a value of -1 in this field represents the first or continuation block and the
block contains 200 bytes of data. The last block of data will contain a positive
number in this field that represents the number of characters in the last block.
253 to 254
Number of characters transmitted (0 to 200) from last block write Port 2
255 to 454
Port 2 data received
455
Reserved
