MVI56E-GSC/GSCXT ♦ CompactLogix or MicroLogix Platform Reference
Enhanced Generic ASCII Serial Communication Module User Manual
ProSoft Technology, Inc. Page 101 of 140
April 24, 2017
GSCUTIL
This data type creates tags needed for sample ladder logic sequencing and
control. You can think of these tags mostly as a 'scratchpad' for the sample logic
to keep track of where it is in the processing cycle. These tags also help control
receiving strings longer than 200 characters.
4.5.3 Controller Tags
The controller tags associated with the sample ladder logic are all contained in
and organized by the data structures and tag arrays created by the previously
described User-Defined Data Types (page 93). Tags are arranged in a
hierarchical structure and grouped by function.
