MVI56E-GSC/GSCXT ♦ CompactLogix or MicroLogix Platform Reference
Enhanced Generic ASCII Serial Communication Module User Manual
ProSoft Technology, Inc. Page 91 of 140
April 24, 2017
Byte Offset
Description
16 to 17
RTS On Delay
18 to 19
RTS Off Delay
20 to 21
Handshaking
22 to 23
Receive Termination Character Count
24 to 35
Receive Termination Characters
36 to 27
Receive Packet Length
38 to 39
Receive Message Timeout
40 to 41
Receive Intercharacter Delay Timeout
42 to 43
Transmit Termination Character Count (Not Used)
44 to 55
Transmit Termination Characters (Not Used)
56 to 57
Transmit Packet Length (Not Used)
58 to 59
Transmit Message Timeout
60 to 61
Transmit Intercharacter Delay Timeout (Not Used)
62 to 63
Minimum Message Transmit Delay
Port 2
Byte Offset
Description
64 to 65
Enabled
66 to 67
Termination Type
68 to 69
Baud Rate
70 to 71
Parity
72 to 73
Data Bits
74 to 75
Stop Bits
76 to 77
RTS On Delay
78 to 79
RTS Off Delay
80 to 81
Handshaking
82 to 83
Receive Termination Character Count
84 to 95
Receive Termination Characters
96 to 97
Receive Packet Length
98 to 99
Receive Message Timeout
100 to 101
Receive Intercharacter Delay Timeout
102 to 103
Transmit Termination Character Count (Not Used)
104 to 115
Transmit Termination Characters (Not Used)
116 to 117
Transmit Packet Length (Not Used)
118 to 119
Transmit Message Timeout
120 to 121
Transmit Intercharacter Delay Timeout (Not Used)
122 to 123
Minimum Message Transmit Delay
