ProSun V3 - Assembly Step 5: Fan Panel Attachment; Connecting Fan Panel to Control Panel

65
MARK76V3002 Rev 3
Remove the Fan Panel from it's box. Remove security plates and screws at the top
of the panel using an Alan wrench.
Retrieve the step stool.
Hook the Fan Panel to the Control Panel at the top of the unit.
Screw the security plate back in place, as previously done in steps 2 and 3.
Control Panel
Fan Panel
Door Panel
5
A
B
Control Panel
Door Panel
Top view
Security Plate
Security Srews
