ProSun V3 - Optional T-Max Timer Installation; T-Max Timer Connection Steps

46
MARK76V3002 Rev 3
Optional T-Max
Power Chord
Unscrew and remove top.
1
2
Pin 1
neutral
Pin 3
live
Male
Female
If you are adding a T-Max timer to your V3 follow the steps below.
*For commercial use only
Remove the male end of part from tanning unit.
