Protec 3200 - Programming Details

93-331-73 Issue 2 Page 17 of 32 © Protec Fire Detection PLC 2013
12.0 Programming Details
In general the front panel buttons and some indications have the following alternate functions when
the 3200 is in programming mode.
When Access Level 3 programming functions are being performed the 'Level 3 Accessed' indicator will
be illuminated and the ‘Supply Present’ indicator will flash.
Button 1 Toggle zone 1 state.
Button 2 Toggle zone 2 state.
Button 3 Scroll.
Button 4 Back / Exit / Program.
General Test Indicator Programming of zones into test mode
General Disablement Programming of zone disablements
Alarm Outputs Disabled Programming of alarm disablements
Alarm Fault Programming of EOL. type
PSU Fault Programming of non-latching zones
Aux 24V. Fault Programming of zones into coincidence
