93-331-73 Issue 2 Page 4 of 32 © Protec Fire Detection PLC 2013
1.0 3200 System Overview
The Protec 3200 fire alarm system features:
• 2 detection zones.
• 2 monitored alarm circuits rated at 150mA each.
• Common negative (allowing three wire operation).
• Re-sounding of outputs if a zone changes from automatic to manual activation
• Three auxiliary inputs: Keyswitch, Class Change and Remote Alarm.
• Global Fire and Global Fault clean contact connections.
• Monitored Auxiliary 24V output (Overload Protected, 100mA maximum).
• Capacitive or resistive detector circuit end of line monitoring (programmable).
• Extensive range of engineering functions accessed via 5 digit entry codes:
• Disablement of zones.
• Coincidence operation.
• Test zones.
• Non-latching zones.
• Disablement of alarm circuits.
• End of line type selection.
• Low quiescent current of 15mA (24V dc supply, mains fail fault, no external equipment).
Note: Due to a policy of continuous improvement Protec Fire Detection plc. reserve the right to alter
the specification without prior notice.
