Protec 3200 - 3200 Programming Quick Reference Guide

93-331-73 Issue 2 Page 30 of 32 © Protec Fire Detection PLC 2013
Appendix 4 - 3200 Programming Quick Reference Guide
FUNCTION Level Program
Indicator
Zone Indication
Test Mode 2/3 General Test Relevant Zones
Disable Zones 2/3 General Disablement Relevant Zones
Disable Alarms 2/3 Alarm Outputs Zone 1 lit – Circuits 1 and 2 are disabled
Set Coincidence 3 Aux. 24V Fault Zone 1 lit - Zone 1&2 coincidence
Set Non-Latching 3 Power Supply Fault Relevant Zones
Set end of line type 3 Alarm Fault Zone 1 lit , EOL is resistive
Please note that any changes to the system program are not permanently stored until button 4 has
been pressed at access level 2 for level 2 programming functions or access level 3 for level 3
programming functions.
