Proteus DOLPHIN V4 - Final Assembly Adjustments

1. The height and seat position can be
adjusted,To adjust the height, loose the knob
( 30 ) and pull it out to adjust seat post ( 04 )
to a desired height, then fasten the knob. To
adjust seat position, loose the knob ( 42 )
and adjust saddle ( 11 ) to a desired position,
then fasten the knob.
2. To Adjust tension, turn tension control
clockwise to increase tension from 1 ( low )
to 8 ( high ), and vice versa.
NOTE : "height indicator" has max. and min.
indication lines on seat post, please
use slots between these two lines.
h. Final adjustment
31
42
30
11
15
( CCW )
( CW )
Tension control
1
8
high
low
