PS Engineering PMA8000G User Manual

PS Engineering
PMA8000G IntelliAudio Audio Selector Panel With flightmate®
Installation and Operator’s Manual
200-890-0912 Page 2-12 Rev. 7, July 2017
2.10 PMA8000G Pin assignments
J1
Function
J2
Function
1
Marker Antenna
1
Pilot Phones Lo
2
Marker Ant Lo
2
Copilot Phones Lo
3
Satellite Telephone Audio In
3
Copilot Phones (L)
4
Satellite Telephone Audio Low
4
Copilot Phones (R)
5
Satellite Telephone Mic Audio
5
Lights low
6
No Connect
6
14/28 V Lights
7
ADF Audio (Control with AUX)
7
14/28 V Lights
8
ADF Audio Lo (Control with AUX)
8
Aircraft Power
9
Com 1 Audio
9
Aircraft Power
10
Com 1 Audio Lo
10
Aircraft Ground
11
Com 1 Mic
11
Aircraft Ground
12
Com 1 Mic Key
12
PA Mute
13
Com 2 Audio
13
Mute #2
14
Com 2 Audio Lo
14
Mute #2
15
Com 2 Mic
15
Unswitched 4 Audio
16
No Connect
16
Pilot Phones (L)
17
Nav 1 Audio
17
Alert Trigger #1
18
Nav 1 Audio Lo
18
AUX logic output
19
Nav 2 Audio
19
Alert Trigger #2
20
Nav 2 Audio Lo
20
Swap/ICS Remote
21
AUX 2 Audio (Control with AUX)
21
Swap Lo
22
AUX 2 Audio Lo (Control with AUX)
22
Playback
23
AUX input (Control with AUX)
23
Music 1 (L)
24
Alert Trigger #4
24
Music 1 (R)
25
No Connect
25
Music 1 Lo
26
No Connect
26
Music 2 (L)
27
No Connect
27
Music 2 (R)
28
Aural Message Acknowledge
28
Music 2 Lo
29
Unswitched 3 Audio
29
CVR Out
30
Com 2 Mic Key
30
Alert Trigger #3
31
Unswitched 1 Audio
31
Pilot Phones (Rt)
32
Unswitched Lo
32
Copilot Mic Audio
33
Pilot Mic Audio
33
Copilot Mic PTT
34
Pilot Mic PTT
34
Copilot Mic Lo
35
Pilot Mic Lo
35
Pass 1 Mic Audio
36
Ext IM MKR
36
Pass 1 Mic Audio Lo
37
Ext OM MKR
37
Pass 2 Mic Audio
38
Ext MM MKR
38
Pass 2 Mic Audio Lo
39
MM Sense
39
Pass 3 Mic Audio
40
Pass HP (L)
40
Pass 3 Mic Audio Lo
41
Pass HP (R)
41
Pass 4 Mic Audio
42
Pass HP Lo
42
Pass 4 Mic Audio Lo
43
Unswitched 2 Lo
43
Speaker Lo
44
Unswitched 2 Audio
44
Speaker Output
2.11 Wiring Checkout
After wiring is complete, verify power is ONLY on pins 8 and 9 of the J2 and airframe ground on connect-
or pins 10 and 11. Failure to do so will cause serious internal damage and void PS Engineering's warranty.
