Page #5 background imageLoading...
Page #5 background image
PS Engineering
PMA8000G IntelliAudio Audio Selector Panel With flightmate®
Installation and Operator’s Manual
200-890-0912 Page 1-2 Rev. 7, July 2017
volume knob controls the intercom level for the pilot and copilot, while the large knob controls the passen-
ger intercom volume. Intercom squelch is automatic.
A 3-light, 75 MHz Marker Beacon receiver is integrated in the PMA8000G. This provides the necessary
Marker Beacon lights and audio indications necessary for that portion of an Instrument Landing System
(ILS) approach. A pushbutton labeled MKR allows the pilot select high or low sensitivity as well as test
and mute modes.
In the PMA8000G, a Bluetooth® wireless interface is available for wireless telephone and music connec-
tion.
Our newest innovation is flightmate®, a tool that can improve flight safety and reduce workload. Having
flightmate on board will help to improve the pilot’s ability to recall pertinent information about the flight.
Flightmate® is the world’s first audio checklist system integrated into an audio panel. It is pilot configura-
ble by recording messages as desired with 2 ½ minutes of storage. No computer or special equipment is
required.
1.4 APPROVAL BASIS
FAA TSO Approval
The PMA8000G-series Audio Selector Panels are FAA approved under TSO C50c (Audio Amplifiers)
TSO C35d (Marker Beacon Receivers) and TSO C71 (DC to DC Converters, ETSO C50c/ and 2C53d.
All systems comply with relevant portions of EUROCAE RTCA MPS WG No. 7/70, DO-143 and (Marker
Beacon Receivers), ED-14C/DO-160C (Environmental Conditions and Test Procedures for Airborne
Equipment), ED12B/DO-178B, Level D (Software Considerations for Airborne Equipment) and ED-
18/DO-214 (Audio Systems Characteristics and Minimum Operational Performance Standards for Aircraft
Audio Systems).
Operation is subject to the following conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired opera-
tion.
1.5 SPECIFICATIONS
TSO COMPLIANCE
Marker Beacon:
FAA TSO C35d, Class A ETSO 2C35d
Audio Selector/Intercom:
FAA TSO C50c, Class 1a ETSO C50c
USB Power Converter
FAA-TSO C71
APPLICABLE DOCUMENTS:
RTCA/DO-214 RTCA/DO-143 RTCA/DO-160D
RTCA/DO-178B DO-254
ENVIRONMENTAL Qualifications:
A1D1CABSMXXXXXXZBABATBXXE2XXX
Operating Temperature Range:
-15º C to 55ºC
Altitude:
Up to 50,000 feet in an non-pressurized area
DIMENSIONS:
Height: 1.3 in. (3.3 cm) Width: 6.25 in. (15.9 cm)
Depth behind panel 7.15 in. (18.16 cm)
WEIGHT
PMA8000G Unit
Rack with connectors
1.34 lb. (0.61 kg)
0.51 lb. (0.24 kg)
POWER REQUIREMENTS (Including Internal Lighting):
Voltage:
11 to 33 VDC
Maximum Current:
2.5 Amp (Externally protected by a 5A pull-type break-
er)
USB Charging Port:
Voltage - +5VDC
Current - 2.0A (10W Maximum) output, short circuit
and over-current protected
