PS Engineering PMA8000G User Manual

PS Engineering
PMA8000G IntelliAudio Audio Selector Panel With flightmate®
Installation and Operator’s Manual
200-890-0912 Page 1-4 Rev. 7, July 2017
1.6 EQUIPMENT SUPPLIED
1 ea. of the following units:
Model
Description
Part Number
PMA8000G
Audio Panel with IntelliAudio®, Marker, Stereo Intercom, and
Bluetooth connectivity plus flightmate® message system
050-890-0912
PMA8000G
Audio Panel with IntelliAudio®, Marker, Stereo Intercom, and
Bluetooth connectivity plus flightmate® message system. In-
cludes PS Streamer
050-890-0913
PMA8000GInstallation Kit: 250-890-0000
Description
Quantity
Part
Number
Installation rack assembly
1
430-890-0040
Rack back plate
1
430-890-0050
44-pin connector kit
2
120-891-2045-
Backshell, connector
2
625-025-2465
Backshell Retainer
2
431-881-0100
4 40 X 7/16 screw w/nylon patch
4
475-440-0007
4 40 X 3/8 screw w/nylon patch
4
475-440-1038
4-40 x ¼” screw with lock washer
2
475-440-0001
Solder Lug
2
475-009-0001
Cable Clamp
1
625-001-0002
#6-32 x ½” Flat head Philips screw
6
475-632-0012
#6-32 Clip Nut
6
475-630-0002
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
a. Circuit Breaker: 1 ea; 5 amp PULL TYPE REQUIRED for PMA8000G
b. Speaker, 4 
c. Headphone Jacks (Stereo, as Required)
d. Microphone Jacks (as Required)
e. Headphones, 150  (Stereo), up to 6 as required
f. Microphones, up to 6 as required
g. Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed)
h. Interconnect Wiring
1.8 LICENSE REQUIREMENTS
None
PMA8000G Bluetooth™ Radio approval:
 FCC ID: QOQWT32AE
 Industry Canada ID: 5123A-BGTWT32AE
 CE EMC Directive 89/336/EEC as amended by Directives 92/31/EEC and 93/68/EEC
