PS Engineering
PMA8000G IntelliAudio Audio Selector Panel With flightmate®
Installation and Operator’s Manual
200-890-0912 Page 2-1 Rev. 7, July 2017
Section II - INSTALLATION
2.1 GENERAL INFORMATION
2.1.1 SCOPE
This section provides detailed installation and interconnection instructions for the PS Engineering
PMA8000G Audio Selector Panel/Intercom/ with internal Marker Beacon.
Please read this manual carefully before beginning any installation to prevent damage and post-installation
problems. Installation of this equipment requires special tools, test equipment (refer to section 2.13.1) and
knowledge as required by 14 CFR 65.81 (b).
2.1.2 Certification Requirements
NOTE
The PMA8000G requires specialized knowledge and tools for an effective installation. An appropriately
rated Certified Aircraft Repair Station must install this equipment in accordance with applicable regula-
tions. PS Engineering, Incorporated warranty is not valid unless the equipment is installed by an authorized
PS Engineering, Incorporated dealer.
Failure to follow any of the installation instructions, or installation by a non-certified individual or agency
will void the warranty, and may result in an unairworthy installation.
2.2 Unpacking and Preliminary Inspection
Use care when unpacking the equipment. Inspect the units and parts supplied for visible signs of shipping
damage. Examine the unit for loose or broken buttons, bent knobs, etc. Verify the correct quantity of com-
ponents supplied with the list in Section 1.6. If any claim is to be made, save the shipping material and con-
tact the freight carrier. Do NOT return units damaged in shipping to PS Engineering. If the unit or accesso-
ries show any sign of external shipping damage, contact PS Engineering to arrange for a replacement.
Under no circumstances attempt to install a damaged unit in an aircraft. Equipment returned to PS Engi-
neering for any other reason should be shipped in the original PS Engineering packaging, or other UPS
approved packaging.
2.3 Equipment Installation Procedures
2.3.1 Cooling Requirements
Forced air-cooling of the PMA8000G is not required. However, the units should be kept away from heat
producing sources (i.e. defrost or heater ducts, dropping resistors, heat producing avionics) without ade-
quate cooling air provided.
2.3.2 Mounting Requirements
The PMA8000G must be rigidly mounted to the instrument panel of the aircraft structure, within view and
reach of the pilot position(s). Installation must comply with FAA Advisory Circular AC 43.13-2B, or other
FAA-approved aircraft technical data. The unit may be mounted in any area where adequate clearance for
the unit and associated wiring bundle exist.
To prevent noise, avoid installing the unit close to high current devices or systems with high-voltage pulse
type outputs, such as DME or transponders. Avoid running the interconnecting bundles near any high cur-
rent wires.
2.3.3 Audio Panel Mounting Rack Installation
Remove the unit from the mounting tray by unscrewing the 3/32" hex-head screw that is in the center of the
unit. Use caution to avoid hitting the photo-detector lens. Carefully slide the unit free of the tray. Set the
unit aside in a safe location until needed. Install the tray using six clip nuts (475-630-0002), and six FHP
6-32 x ½" screws (475-632-0012). The audio selector panel must be supported at front and rear of the
mounting tray.
