Figure 28. TCP Client
Table 7. Detail parameters of TCP client
Items
Description
Default
Enable
Whether this link is enabled, ON (enabled)/OFF (disabled ).
ON
Name
Set the name of this link.
TCPC_X
Description
Set the remark information of this link.
TCPC_X
Server Address
IP or domain name of server.
test.cn
Server Port
Listening port of server.
None
Local Port
Port of W630s.
0
Heartbeat Packet
Set whether to enable the heartbeat packet function, ON
(enable)/OFF (disable ).
OFF
Heartbeat packet
type
HEX: hexadecimal type,
ASCII: character type.
HEX
Heartbeat packet
data
Heartbeat packet data content.
None
Heartbeat packet
time
The time interval for sending heartbeat packets, unit: seconds.
60
Registration Packet
NONE: turn off the registration packet,
Custom: Users can define the content of the registration
package themselves,
MAC: Use the MAC of the WAN port of the device as the content
of the registration packet.
None
Registration packet
type
Custom registration packet type,
HEX: hexadecimal type,
ASCII: character type.
HEX
Registration packet
data
Registration packet data content.
None
Registry Packet
Contained In
Send a registration packet when connecting to the server,
Add the registration packet to the front of each data packet
sent to the server.
Sent once when
connecting
Transmission Mode
Pass- Through: transparent transmission mode,
Modbus RTU: Modbus RTU and Modbus TCP transfer.
Pass- Through
Host Polling
ON: Multiple host polling mode.
OFF: Modbus RTU/TCP protocol conversion mode.
OFF
Polling Timeout
Unit: ms
Range: 10-6000 ms
200
Modbus Timeout
Response
ON: Enable Modbus Timeout Response.
OFF: Disable Modbus Timeout Response.
OFF
