PUSR USR-W630s - TCPS Mode(TCP Server)

USR-W630s User Manual
pusr.com
- 24 -
Bind
COM1-485: Data is transmitted by RS485 only.
COM2-232: Data is transmitted by RS485 only.
COM1+COM2：Data is transmitted by RS485 and RS232 both.
COM1-485
TLS
The version can be TLS1.0 or TLS1.2.
OFF
TLS Authentication
NO AUTH: No certificate verification is required.
Server: Only the server certificate is verified.
BOTH: Both client and server certificates need to be validated.
NO AUTH
Offline Data Cache
ON: Offline data will be cached and sent when get online
again.
OFF: Offline data will be not cached.
OFF
Data Overflow
handling
Discard old Data: Store the latest data.
Discard New Data: When the storage space is used up, no new
data will be stored.
Discard old Data
Caching Method
Length Limit/Package Quantity Limit
Length Limit
Illustrate:
 The TCP Client mode can be used in conjunction with the USR custom indicator light. When the TCP Client
connects to the server, the USR The indicator light comes on,
Supports TLS encrypted transmission and offline data caching functions.
5.2.2. TCPS Mode(TCP Server)
Enable TCPS mode.
Figure 29. TCP server
