USR-W630s User Manual
pusr.com
- 28 -
Figure 33. UDPS settings
Table 10. Detail parameters of UDPS
Items
Description
Default
Enable
Whether this link is enabled, ON (enabled)/OFF (disabled ).
ON
Name
Set the name of this link.
UDPS_X
Description
Set the remark information of this link.
UDPS_X
Local Port
Port of W630s.
None
Transmission Mode
Pass- Through: transparent transmission mode,
Modbus RTU: Modbus RTU and Modbus TCP transfer.
Pass- Through
Bind
COM1-485: Data is transmitted by RS485 only.
COM2-232: Data is transmitted by RS485 only.
COM1+COM2：Data is transmitted by RS485 and RS232 both.
COM1-485
5.2.5. MQTT Mode
5.2.5.1. Basic settings of MQTT
Select MQTT mode.
Figure 34. MQTT settings
