USR-W630s User Manual
pusr.com
- 27 -
Heartbeat packet
type
HEX: hexadecimal type,
ASCII: character type.
HEX
Heartbeat packet
data
Heartbeat packet data content.
None
Heartbeat packet
time
The time interval for sending heartbeat packets, unit: seconds.
60
Registration Packet
NONE: turn off the registration packet,
Custom: Users can define the content of the registration
package themselves,
MAC: Use the MAC of the WAN port of the device as the content
of the registration packet.
None
Registration packet
type
Custom registration packet type,
HEX: hexadecimal type,
ASCII: character type.
HEX
Registration packet
data
Registration packet data content.
None
Registry Packet
Contained In
Send a registration packet when connecting to the server,
Add the registration packet to the front of each data packet
sent to the server.
After connection
Transmission Mode
Pass- Through: transparent transmission mode,
Modbus RTU: Modbus RTU and Modbus TCP transfer.
Pass- Through
Bind
COM1-485: Data is transmitted by RS485 only.
COM2-232: Data is transmitted by RS485 only.
COM1+COM2：Data is transmitted by RS485 and RS232 both.
COM1-485
5.2.4. UDPS Mode(UDP Server)
Select UDPS mode.
