Page #21 background imageLoading...
Page #21 background image
9B.1 Tamper Switch
If required assemble the
tamper switch from the
optional kit of parts as
indicated
If necessary place the
transformer and fasten
into position using the
screws supplied with
the transformer kit
Wall
Mounting
9B Panel Assembly - Metal
Rins163 Issue 9 Page 21
