11.11.13 Zone Tamper Alarm Reporting Codes
Enter
Enter 2 digits for each tamper zone. To disable an event insert blanks for both digits.
To use hex codes, use the up key to select the character required and the
key to accept.
Example
Tamper zone 1
Tamper zone 2
Tamper zone 3
Tamper zone 4
Tamper zone 5
Tamper zone 6
Tamper zone 7
Tamper zone 8
11.11.14 System Set / Unset Reporting Codes
Enter
Enter 2 digits for seven reporting codes. To disable an event insert blanks for both digits.
To use hex codes, use the up key to select the character required and the
key to accept.
Example
Set A
Set B
Set C
Set C
Duress Set
Duress Unset
Confirmed Alarm Code
Reporting codes are automatically stored after the 16th key press or
key to accept.
11.11.15 User set reporting codes
Enter
Enter 2 digits for seven reporting codes. To disable an event insert blanks for both digits.
To use hex codes, use the up key to select the character required and the
key to accept.
Example
Set User 1
Set User 2
Set User 3
Set User 4
Set User 5
Set User 6
Set User 7/Keyswitch
Reporting codes are automatically stored after the 16th key press or
key to accept.
Page 36
