EURO 46, 162 & 280 Programming Manual
Page: 5
2.2 Wired Input Mappings
EURO *46 EOL/DP 162iD 162EOL 280iD 280EOL
iD
End Station - 1-30 - 1-30 -
EOL
End Station 1-8 151-158 1-8 241-248 1-8
ZEM0 9-16 - 9-16 - 9-16
ZEM1 17-24 - 17-24 - 17-24
ZEM2 25-32 - 25-32 - 25-32
ZEM3 33-40 - 33-40 - 33-40
ZEM4 - - 41-48 - 41-48
ZEM5 - - 49-56 - 49-56
ZEM6 - - 57-64 - 57-64
ZEM7 - - 65-72 - 65-72
ZEM8 - - 73-80 - 73-80
ZEM9 - - 81-88 - 81-88
ZEM10 - - 89-96 - 89-96
ZEM11 - - 97-104 - 97-104
ZEM12 - - 105-112 - 105-112
ZEM13 - - 113-120 - 113-120
ZEM14 - - 121-128 - 121-128
ZEM15 - - 129-136 - 129-136
ZEM16 - - 137-144 - 137-144
ZEM17 - - 145-152 - 145-152
ZEM18 - - - - 153-160
ZEM19 - - - - 161-168
ZEM20 - - - - 169-176
ZEM21 - - - - 177-184
ZEM22 - - - - 185-192
ZEM23 - - - - 193-200
ZEM24 - - - - 201-208
ZEM25 - - - - 209-216
ZEM26 - - - - 217-224
ZEM27 - - - - 225-232
ZEM28 - - - - 233-240
ZEM29 - - - - 241-248
RKP0 41-42** 159-160 153-154 249-250 249-250
READ/RKP1 43-44** 161-162 155-156 251-252 251-252
READ/RKP2 45-46** - 157-158 253-254 253-254
READ/RKP3 - - 159-160 255-256 255-256
READ/RKP4 - - 161-162 257-258 257-258
READ/RKP5 - - - 259-260 259-260
READ/RKP6 - - - 261-262 261-262
READ/RKP7 - - - 263-264 263-264
READ/RKP8 - - - 265-266 265-266
READ/RKP9 - - - 267-268 267-268
READ/RKP10 - - - 269-270 269-270
READ/RKP11 - - - 271-272 271-272
READ/RKP12 - - - 273-274 273-274
READ/RKP13 - - - 275-276 275-276
READ/RKP14 - - - 277-278 277-278
READ/RKP15 - - - 279-280 279-280
READ = Reader
RKP = Remote Keypad
ZEM = Zone Expander Module
