EURO 46, 162 & 280 Programming Manual
Page: 17
6. 'Input Attributes' will be displayed. If any attributes are needed for
the input, press and press or to select between the
attribute enable/disable options and press to go to the next
attribute.
7. 'Enter Name' will be displayed. Enter the name of the input and
press . This will be displayed if it is activated or when a fault
occurs.
8. 'Enter Location' will be displayed. Enter the location of the input
and press . This will be displayed if it is activated or when a
fault occurs after the name of the input has been shown.
9. Press or to select another input to program or press the
key to return to the Engineer menu.
4.7 Assign Keypads/Readers
Any additional keypads or readers must be addressed correctly before enabling them in this function.
The EURO control panel keypad is automatically addressed as '00' on initial power up. Refer to the
installation manual (RINS1529) for more information.
4.7.1 Address
Address '00' is used for the first keypad installed on the EURO control panel.
NOTE: Each keypad has its own individual menu that programs the key-click volume, tag volume
and master volume. It will address a keypad, show the status of the keypad inputs (if
programmed), force the backlight on or off and the identification number of a tag (once a tag is
presented). The PA/Fire timer can be programmed. This menu also addresses the keypad.
To enter the keypad menu, press and hold the key until ‘SECURITY CODE’ is displayed, and
then enter ‘2000’. This function is also used to address the keypad.
4.7.2 Type
[0] Keypad. [1] Reader. [2] Not Used.
4.7.3 Reader is
If a tag reader is installed, the following options can be assigned:
[0] Set Point: Reader used for setting and unsetting.
[1] Ward Control: A reader can be used to create wards. For example: A keypad may control a
full area, but in the area you may wish to control certain inputs only.
[2] Access Control: If an access control system is installed then the reader must be
programmed as this type. The lock open time and door open time can be programmed (in
seconds).
[3] Unset Only: If the Reader is to be used as an unset device only, select this type.
[4] Entry Control: Used to lock/unlock doors. The external or internal reader can have
magnetic locks connected to them. This option is used in conjunction with ‘tag opens doors’ in
'SITE OPTIONS' page: 26. The lock open time and door open time can be programmed (in
seconds).
4.7.4 Set Point Sets
A “Setting Point” means that you can program the keypad / reader to set certain Areas only. This
is used in conjunction with the Areas allocated to a user code.
For example, if a user code is programmed to operate Areas ‘A’ and ‘B’, but the keypad / reader
is only programmed to Set Area ‘A’, then the system will set only Area ‘A’.
4.7.5 Set Point Unsets
An “Unsetting Point” means that you can program the keypad / reader to unset certain Areas
only. This is used in conjunction with the Areas allocated to a user code.
For example, if a user code is programmed to operate Areas ‘A’ and ‘B’, but the keypad / reader
is only programmed to Unset Area ‘A’, then the system will Unset only Area ‘A’.
Shunt Inputs[02]
Input 02
Input Areas
[ A ]
Input Attribtes?
