EURO 46, 162 & 280 Programming Manual
Page: 47
Appendix D. Output Types
Type Active Restore
0000 Not Used (permanently off)
0001 Fire At alarm When a valid code is entered
0002 Hold Up Any
At a HU or Duress alarm
(This includes keypad HU)
When a valid code is entered
0003 Intruder Any At alarm, while system is disarmed
At first valid code entry and at end
of confirm time.
0004 Final Set All When system is FULLY armed At code entry to unset
0005
Misoperation Any
(Abort)
When system is silenced after any
‘intruder’ output is triggered
After 2 minutes
0006 Confirmed Any
When further input active in any
area after ‘intruder’ alarm
At next code entry
0007 Tamper Any Any tamper alarm
At code entry to silence
And at end of confirm time.
0008 Duress
At a Duress alarm (i.e. from a
keypad)
When a valid code is entered
0009 HU Device Any At alarm on a HU input only When a valid code is entered
0010 Gas At alarm When a valid code is entered
0011 Set Fail
Pre-set time after start of exit time,
if exit procedure is not complete
At code entry to rearm
0012 Entry Deviation
When deviation from entry route
occurs, during entry time
At code entry to unset
0013 Secure Intruder Any
At alarm, after exit time started,
until unset
At first valid code entry
and at end of confirm time.
0014 Siren Any When alarm live
When alarm silenced or when siren
timer expires
0016 Strobe Any When alarm live
When alarm silenced or when
strobe timer expires
0017 Omit Rearm Any
Input omitted if active (or in alarm
condition) at the end of confirmation
time.
When system disarmed
0018 Unconfirmed Any Any intruder or Tamper alarm At code entry to silence
0019 Can Set All
If all inputs and technical faults in
system are clear. Also once entry
time has started
If fault exists, and after final set
0020 Exit Starts All At start of exit time to set LAST area At code entry to unset FIRST area
0021 Exit Starts Any
When exit time starts to set FIRST
area
At code entry to unset LAST area
0022 Final Set Any When FIRST area is set At code entry to unset LAST area
0023 Strobe Set Fail Works similar to output 016, but also fires if the set fail timer expires.
0025 Keyswitch unset
This output turns on for 5 seconds when the system is disarmed via a
keyswitch input (pulsed or latched)
0026 Set with Omit Activates when inputs are omitted on setting
0028 Power Fault
Active during low volts and battery faults*. Restores at code entry after
fault cleared.
0029 Confirmed Intruder Any
When more than one intruder alarm
activates
At next code entry
0030 Confirmed Hold Up Any
When more than one confirmed hold
up activates
At next code entry
0031 Entry Live during any exit time
0032 Exit Live during any entry time
0033 Entry/Exit
Live during any entry or exit time
