quadient DS-85i - Specifications; Technical Specifications

Specifications11
Technical Specifications
DS-85i, FPi 5700, FD6406Model
Inserter system for medium office use.Type
4000 inserts per hour, depending on applic-
ation.
Theoretical max. speed
100V AC/50Hz/3.0 Amps.Power consumption
115V AC/50/60Hz/3.0 Amps.
230V AC/50Hz/1.5 Amps.
100V: +6% / -10%
115V: +6% / -10%
230V: +10% / -10%
Voltage tolerance
100/115 Vac: T 5.0 A, 125 V .Fuse
Time lag, 5.0 Amps. rated current, 125 V.
230 Vac: T 2.5 A H, 250 V.
Time lag, 2.5 Amps. rated current, high
breaking capacity, 250 V.
RED (Radio Equipment Directive)
2014/53/EU
Approvals
FCC certification conform 47CFR, part 15
CB Certificate conform IEC 62368-1
UL Listed I.T.E. (Information Technology
Equipment)
Conform UL-IEC 62368-1, file E153801
Conform NEN-EN-IEC 62368-1
and derivatives.
