CubiScan 25 Service Manual 1
Chapter 1
Diagnostics
This section describes the diagnostics procedures for the CubiScan 25. This chapter is divided
into the following sections:
• “Booting Process Errors” on page 1
• “Dimensional Errors” on page 3
• “Gate Movement Errors” on page 7
• “Miscellaneous Errors” on page 9
• “Scale Errors” on page 10
The figure below shows parts commonly referred to in the following sections.
Booting Process Errors
This section describes the various booting process errors that can occur with the CubiScan 25.
Refer to the following sections for more information.
Figure 1
CubiScan 25 Parts
Glass
Platform
Scale Plate
Touchscreen
Gate
Load Cell
Summing Box
Shroud
Controller Box
Encoder
Proximity Sensor
