CubiScan 25 Service Manual 90
Appendix B
Parts List
Following is a list of parts that can be purchased for the CubiScan 25 as spare parts or if
replacement is necessary.
Part No. Description Quantity/Unit
10083 AC Power Cord 1
10558 Scale Card PCB 1
12344 1/2'' Diameter Ball 4
12841 Infrared Receive PCB 2
12844 Infrared Transmit PCB 2
12956 Infrared Filter, 14'' 2
13340 Proximity Sensor 1
13351 1 Amp Fuse 2
13372 Load Cell Summing PCB 1
13411 USB to Ethernet Adapter 1
13620 Infrared Filter, 12.8'' 2
13624 Calibration Cube, 5'' x 3'' x 2'' 1
14066 Leveling Foot 4
14090 Touchscreen Assembly 1
14100 Main Controller Assembly 1
14119 Glass Plate 2
14124 Scale Plate 1
14159 Motion Encoder with Connector 1
14161 Encoder Magnet 1
14165 User Manual (PDF) 1
14309 10 kg Load Cell 4
14326 CAT 5e Patch (Ethernet Cable), 10 ft 1
