CubiScan 25 Service Manual 13
Chapter 2
Scale Calibration
To calibrate the CubiScan 25 scale, you will need an official test weight up to 15 pounds (6 kg) (it
is recommended that you calibrate with the maximum weight).
IMPORTANT: Do not begin scale calibration until you have the test weight. Calibrating without
an accurate known weight (within .01 of a lb/kg) can make all future weight readings inaccurate.
When calibrating the scale, the CubiScan 25 must be stable with no movement of the platform
such as that caused by vibration or air movement.
Scale Calibration
Take the following steps to calibrate the CubiScan 25 scale.
1. Tap
[Menu] at the main screen.
The menu buttons are displayed.
Figure 4
Main Screen
