Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 57
Dimension Units
This command is used to set the dimension units to either English (inches) or metric
(centimeters) mode.
51 1 Wgt./Dim.Wgt Unit Alpha (E/M) 45h or 4Dh
52 1 Comma Alpha (,) 2Ch
53 1 Factor Identifier Alpha (F) 46h
54 4 Factor Numeric 0000-9999
58 1 Comma Alpha (,) 2Ch
59 1 Domestic/Int'l. Unit Alpha (D/I) 44h or 49h
60 1 End of Text Control (ETX) 03h
61 1 Carriage Return Control (CR) 0Dh
62 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 4Dh
31Neg. Acknowledge Alpha (N) 4Eh
41
CubiScan/Host
Originated
Alpha (C/H) 43h or 48h
51
Corner Sensor/Measure/
Zero Error
Alpha (C/M/Z) 43h or 4Dh
61End of Text Control(ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
81Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Dim. Unit Command Alpha (") 22h
3 1 English or Metric Alpha (E/M) 45h or 4Dh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Dim. Unit Command Alpha (") 22h
3 1 Acknowledge Alpha (A) 41h
Pos Len Description Type Range ASCII
