Quantum Data 980 - Page 85

980 User Guide Rev. B29
Page 85 August 5, 2011
Real Time Mode – Main
Control Panel
Control Button Descriptions
enables you to show or hide the Auxiliary Channel Analyzer data (DDC
transactions) panel and pause and resume updates to the panel.
 Back - The arrow button enables you to toggle between the current
view and the previous view.
 Mode - The Mode button opens up dialog boxes that enable you to
select the operating mode of the 980. You can control the pass through modes
and HDCP modes.
 Goto - The Goto button enables you to open up various windows in
the 980 interface.
 Hide - The Hide button enables you close the Real Time view and
go to the Capture and Store view.
