TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 6/17 Page 5-39
051-090-019 - Ball Accelerator Parts List
Item
Part Number
Description
1
302-9000-00
ACCELERATOR FRAME
2
302-9010-00
ADJUSTMENT PLATE
3
302-9020-00
TRACK
4
302-9060-00
MOTOR SUPPORT
5
302-9070-00
TENSION BAR
6
302-9075-00
SPECIAL BOLT
7
302-9090-00
TENSION BRACKET
8
302-9095-00
FLANGE BEARING
9
302-9100-00
ACCELERATOR SHAFT
10
302-9120-00
PIN HEAD GUARD
11
302-9180-00
ATTACHMENT PLATE
12
302-9190-00
ATTACHMENT PLATE
13
302-9200-00
ACCELERATOR PULLEY
14
302-9220-00
STABILIZER ARM
15
302-9230-00
ADJUSTMENT ROD
16
302-9030-01
BALL GUARD BRACKET
17
303-9030-00
BELT GUARD
18
304-1560-00
BUMPER PAD
19
304-9000-00
ACCELERATOR BELT
20
304-9010-00
ACCELERATOR MOTOR BELT
21
304-9020-00
TRACK TUBING
22
305-9080-00
ACCELERATOR SPRING
23
333-9110-01
TENSION WHEEL ASSEMBLY
24
333-9140-01
DRIVE WHEEL ASSEMBLY
25
051-130-000
TENPIN ACCELERATOR MOTOR ASSEMBLY
26
R-014
BUMPER PAD
27
302-2410-00
KEY, 3/16
28
7010-002520-050
SCREW, HEX, ¼-20 X ½
29
7010-003118-100
SCREW, HEX, 5/16-18 X 1
30
7012-003118-300
CARRIAGE BOLT, 5/16-18 X 3
31
7016-313118-100
SCREW, FLAT HEAD, 5/16-18 X 1
32
7018-003118-075
SCREW, HEX, 5/16-18 X 3/4
33
7018-303716-075
SCREW, FLAT HEAD, 3/8-16 X 3/4
34
7034-005013-000
NUT, HEX, 1/2-13
35
7036-003118-000
NUT, HEX, 5/16-18, NYLON INSERT
36
7038-003118-000
NUT, HEX, 5/16-18 KEPS
37
7050-028062-006
WASHER, FLAT, 9/32 X 5/8
38
7050-034100-012
WASHER, FLAT, 11/32 X 1 X 1/8
39
7050-040081-006
WASHER, FLAT, 13/32 X 13/16 X 1/16
40
7016-313118-400
SCREW, FLAT HEAD, 5/16-18 X 4
41
7050-040112-012
WASHER, FLAT, 13/32 X 1-1/8 X 1/8
42
7010-003118-075
SCREW, HEX, 5/16-18 X 3/4
43
7060-025046-006
WASHER, ¼, LOCK
44
7060-031057-009
WASHER, 5/16, LOCK
