Pit Assembly Parts List
Item
Part Number
Description
1
304-9030-00
POSITIONING TUBE
2
322-9000-00
BALL ACCELERATOR ASS’Y
3
7010-003118-100
5/16-18 X 1 HEX CAP SCREW
4
7010-003118-175
5/16-18 X 1-3/4 HEX CAP SCREW
5
7010-003118-275
5/16-18 X 2-3/4 HEX CAP SCREW
6
7010-003118-400
5/16-18 X 4 HEX CAP SCREW
7
7012-003118-100
5/16-18 X 1 CARRIAGE BOLT
8
7024-201400-150
14-10 X 1-1/2 HEX/WASHER HEAD SELF-TAPPING SCREW
9
7026-310800-200
#8 X 2 SELF-DRILLING FLAT HEAD SCREW
10
7028-003100-150
5/16 X 1-1/2 LAG SCREW
11
7028-003100-250
5/16 X 2-1/2 LAG SCREW
12
7036-003118-000
5/16-18 NYLON INSERT HEX NUT
13
7050-034068-006
11/32 X 11/16 X 1/16 FLAT WASHER
14
7050-034100-012
11/32 X 1 X 1/8 FLAT WASHER
15
9202043
PIT HOLDING BRACKET, LEFT
16
9202044
PIT HOLDING BRACKET, RIGHT
17
9202045
PIT HOLDING BRACKET
18
9202047
CUSHION STOP PLANK
19
9202049
CUSHION STOP BRACKET
20
9202054
TUBING BRACKET
21
9203052
BALL GUIDE
22
9206055
BALL GUIDE STOPPER
23
9222001
BALL RETURN KICKBACK ASS’Y
24
9222048-4
CUSHION ASSEMBLY, RIGHT
25
9222048-7
CUSHION ASSEMBLY, LEFT
26
9266051
PIT FLOOR, LANE 1
27
9266052
PIT FLOOR, LANE 2
28
M-0376
MAIN CROSS SUPPORT
