TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 6/17 Page 5-47
Double Kickback Parts list
Item
Part Number
Description
1
302-6650-00
SPACER FOR KICKBACK
2
302-6660-00
SPECIAL BOLT FOR KICKBACK
3
30W-0180-45
PINSPOTTER SUPPORT, TENPIN
4
7010-003118-275
5/16-18 X 2-3/4 HEX CAP SCREW
5
7010-003716-275
3/8-16 X 2-3/4 HEX CAP SCREW
6
7012-003716-100
3/8-16 X 1 CARRIAGE BOLT
7
7016-312520-100
1/4-20 X 1 FLAT HEAD MACH SCREW
8
7024-201400-150
14-10 X 1-1/2 HEX/WASHER HEAD SELF-TAPPING SCREW
9
7028-003100-175
5/16 X 1-3/4 LAG SCREW
10
7036-003118-000
5/16-18 NYLON INSERT HEX NUT
11
7036-003716-000
3/8-16 NYLON INSERT HEX NUT
12
7050-034068-006
11/32 X 11/16 X 1/16 FLAT WASHER
13
7050-040081-006
13/32 X 13/16 X 1/16 FLAT WASHER
14
7060-031057-009
5/16 LOCK WASHER
15
9222001
BALL RETURN KICKBACK ASSEMBLY
16
M-0180-37-8
KICKBACK U-BAR, 24
17
M88-0181-03
KICKBACK MOUNTING PLATE
18
M88-0181-04
KICKBACK BRACKET
19
P88-0181-03
PLASTIC PROTECTOR
20
Q88-0181-30L
BALL RETURN MAG3 KICKBACK, LEFT
21
Q88-0181-30R
BALL RETURN MAG3 KICKBACK, RIGHT
22
051-060-000
U-BAR SHIM
