TMS STRING PINSPOTTER OWNER’S MANUAL
400-051-010-01 Rev. Date: 6/17 Page 5-49
Ball Return Kickback Part List
Item
Part Number
Description
1
302-6680-00
DEFLECTOR BLOCK MOUNTING PLATE
2
302-6690-00
DEFLECTOR BLOCK MOUNTING PLATE
3
303-6550-00
PLASTIC RING
4
303-6620-00
BALL DEVIATOR, RIGHT
5
303-6625-00
BALL DEVIATOR, LEFT
6
7016-312520-050
1/4-20 X 1/2 FLAT HEAD MACH SCREW
7
7016-313118-100
5/16-18 X 1 FLAT HEAD MACH SCREW
8
7036-003118-000
5/16-18 NYLON INSERT HEX NUT
9
7046-002520-000
1/4-20 WELD NUT
10
7050-034100-012
11/32 X 1 X 1/8 FLAT WASHER
11
9202001
BALL RETURN CASING
12
9203001-1
PLASTIC RING
13
9203001-2
PLASTIC RING
14
9203001-3
PLASTIC RING
15
9203001-4
PLASTIC RING
16
9266003
DEFLECTOR BLOCK, LEFT
17
9266004
DEFLECTOR BLOCK, RIGHT
